Máy chủ HPE DL385 G10 | AMD 7351 | 16GB RAM | 8SFF CTO

HPE PROLIANT HPE DL385 Gen10 AMD EPYC 7351 CTO SERVER

Processor Name (Tên CPU):

AMD EPYC 7351 (TDP 155/170W )

Processor Number (Số lượng CPU):

1

Processor Speed (Tốc độ xử lý CPU):

Processor Core Available (Lõi CPU):

16 cores - 32 Threads

Processor Cache Installed (Bộ nhớ đệm CPU):

64 MB

Standard Memory (Bộ nhớ RAM mặc định):

HPE 16GB (1x16GB) 1Rx4 PC4-2933Y-R CAS-21-21-21 Registered Smart Memory Kit

Hard Drive Number (Số lượng ổ cứng):

optional - 8SFF drives supported

Storage Controller (RAID Card

HPE Smart Array P408i-p SR Gen10 (Raid 0,1,5,10,50,60) (8 Internal Lanes/ 2GB Cache) 12G SAS PCIe Plug-in Controller

HPE 96W Smart Storage Lithium-ion Battery with 145mm Cable Kit

Network Controller:

HPE Ethernet 1Gb 4-port 366FLR Adapter

Remote Management Software (Phần mềm quản lý hệ thống):

* Standard (Bản tiêu chuẩn): HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download)
* Advanced (Bản nâng cao): Optional - HPE iLO Advanced and HPE OneView Advanced (requires licenses)

System Fan Features (Hệ thống quạt tản nhiệt):

4-standard fans

Power Supply Type (Bộ nguồn

2x HPE 800W Flex Slot Platinum hot-plug power supply

Expansion Slots (Khe cắm mở rộng):

Optical Drive (Ổ đĩa quang):

Not Available

Weight (Trọng lượng):

14.9 kg (32.75 lb) Minimum

23.6 kg (51.5 lb ) Maximum

Product Dimensions (Kích thước W x D x H):

8.73 x 44.55 x 67.94 cm

3.44 x 17.54 x 26.75 inch

Form Factor (Hình dáng bên ngoài):

Warranty Standard Satement (Bảo hành tiêu chuẩn):

3 năm FC NBD

Thông số kỹ thuật nâng cấp

Processor Type:

AMD

Processor Family:

AMD EPYC 72xx-73xx-74xx

Processor Core Available:

8 to 64 core, depending on model

Processor Cache Installed: ):

64 - 256 MB L3, depending on processor

Maximum Memory :

2 TB with 32 x 64GB RDIMM Bus 2933 MT/s, 4 TB with 32 x 128GB LRDIMM Bus 2933 MT/s

Memory Slots: 4 slots :

32 Slot

Memory Type:

HPE DDR4 Smart Memory and HPE Persistent Memory, depending on model

Drive Supported:

8 or 12 or 24 SAS/SATA/SSD (8 SFF Chassis upgradeable to 24 SFF front + 6SFF rear)

Storage Controller :

HPE Smart Array S100i(raid :0,1,5,10) SR Gen10 SW RAID and/or HPE Smart Array E208i-a(raid :01,5,10) SR G10 LH Controller and/or HPE Smart Array P408i-a(0,1,5,10,50,60) , HPE Smart Array P816i-a(0, 1, 5, 6, 10, 50, 60, 1 ADM, 10 Advanced Data Mirroring)

Network Controller:

Embedded 4 x 1GbE Ethernet Adapter (select models) or HPE FlexibleLOM and optional PCIe stand-up cards, depending on model

Remote Management :

HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download); Optional - HPE iLO Advanced, and HPE OneView Advanced (require licenses)

System Fan Features (Hệ thống quạt tản nhiệt):

4-standard fans

Expasions Slots:

3, for detailed description refer to QuickSpecs (quickspecs).

Operating Systems and Virtualization Software

Windows Server 2016-2019,VMware ESXi 6.5 U3 -6.7 U3, Red Hat Enterprise Linux (RHEL) 7.6, SUSE Linux Enterprise Server (SLES) 12 SP4- 15 SP1, Citrix XenServer
