Intel Xeon 6 Processor
32GB (1x32GB) Dual Rank x8 DDR5-6400 CAS-46-45-45 EC8
Cấu hình thêm...
MR416i-o Gen11 x16 Lanes 8GB Cache PCI SPDM
Broadcom BCM5719 Ethernet 1Gb 4-port BASE-T Adapter for HPE
800W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit
|
Processor Name (Tên CPU): |
Intel® Xeon® 6505P (TDP: 150W) |
|
Processor Number (Số lượng CPU): |
1 |
|
Processor Speed (Tốc độ xử lý CPU): |
2.2 GHz |
|
Processor Core Available (Lõi CPU): |
12 Cores - 24 Threads |
|
Processor Cache Installed (Bộ nhớ đệm CPU): |
48 MB L3 cache |
|
Standard Memory (Bộ nhớ RAM mặc định): |
128 GB DDR5-6400 ECC RDIMM (4 × 32 GB HPE Registered Smart Memory) |
| Drive Cage: | HPE ProLiant Compute ML350 Gen12 8SFF Tri-Mode Drive Cage Kit |
|
Storage |
8SFF Tri-Mode drive cage; no HDD or SSD included |
|
Storage Controller (RAID Card) |
1 × HPE MR416i-o Gen11 PCIe x16 Storage Controller, 8 GB cache, OCP, SPDM; includes an HPE 96W Smart Storage Lithium-ion Battery with 260 mm cable |
|
Network Controller: |
BCM5719 OCP3 Adapter – 4 × 1GbE BASE-T RJ45 |
| Interfaces | 1 × optional Serial port – rear 1 × optional DisplayPort – front 1 × VGA port – rear 1 × dedicated HPE iLO management port – rear 1 × iLO Service port – front 5 × USB 3.2 Gen 1 ports (1 front, 2 rear, 2 internal) |
|
Remote Management Software |
HPE iLO 7 Standard; iLO Advanced requires a separate license |
|
System Fan Features |
Standard fans included with the base chassis; the provided BOM does not list the DL3X0 Gen11 1U fan kit |
|
Power Supply Type (Bộ nguồn) |
2 × HPE 800W Flex Slot Platinum Hot-Plug Power Supply Kits |
| Power Cords: | 2 × HPE C13–BS 1363/A, 250V, 10A, 1.83 m FIO Power Cords |
| Expansion Slots (Khe cắm mở rộng): | 4 × PCIe 5.0 x8 slots with the current one-CPU configuration; additional slots require a second CPU and optional risers |
| OCP Enablement Kit: | HPE ProLiant Compute DL3XX/ML350 Gen12 CPU1-to-Rear OCP Slot B x8 Cable Kit |
| Heat Sink | HPE ProLiant Compute ML350 Gen12 Standard Heat Sink Kit |
|
Weight (Trọng lượng): |
23.96 kg ( 52.82 lb) minimum 42.28 kg ( 93.21 lb) maximum |
|
Product Dimensions |
46.2 × 17.4 × 71.2 cm 18.2 × 6.85 × 28 in |
|
Form Factor (Hình dáng bên ngoài): |
4U tower; rack installation requires an optional conversion kit |
|
Warranty Standard Satement |
3 năm |
| Thông số Kỹ Thuật Nâng Cấp | ||
|
Processor Type: |
Intel® Xeon® 6 processors | |
|
Processor Family: |
Intel® Xeon® 6500P series | |
|
Processor Core Available: |
1 × Intel® Xeon® 6505P, 12 cores / 24 threads | |
|
Processor Cache Installed: ): |
48 MB L3 cache | |
|
Maximum Memory : |
Up to 8 TB DDR5 RDIMM with two processors installed | |
|
Memory Slots: |
32 DIMM slots total; 16 available with the current one-CPU configuration | |
|
Memory Type: |
HPE DDR5-6400 ECC Registered Smart Memory (4 × 32 GB installed) | |
|
Drive Supported: |
8SFF U.3 Tri-Mode drive cage; no data drives installed | |
|
Storage Controller : |
HPE MR416i-o Gen11 Tri-Mode RAID Controller, PCIe x16, 8 GB cache (OCP, SPDM) | |
| Remote Management : | HPE iLO 7 Standard; iLO Advanced requires a separate license | |
| Expansion Slots: | 4 × PCIe 5.0 x8 slots with one CPU installed; additional slots require optional risers and, for CPU 2 slots, a second processor | |
|
Operating Systems |
|
|
