Máy chủ LENOVO TS150 E-1225 | RAM 8G | 2LFF Server

ThinkSystem Server LENOVO TS150

Processor Name (Tên CPU):

Intel Xeon E1225 V6(73W)

Processor Number (Số lượng CPU):

1

Processor Speed (Tốc độ xử lý CPU):

3.3 GHz

Processor Core Available (Lõi CPU):

4 cores

Processor Cache Installed (Bộ nhớ đệm CPU):

 8 MB L3

Standard Memory (Bộ nhớ RAM mặc định):

ThinkServer 8GB 2RX8 PC4-2400-E CL15 DDR4-2400 ECC-UDIMM

Hard Drive Number (Số lượng ổ cứng):

Optional : 2/2 LFF SATA/SAS/SATA HOT-Swap Drive bays

Storage Controller (RAID Card

ServeRAID 121I SATA Controller (Raid 0, 1, 10,5)

Network Interface (cổng mạng )

1x 1/10 GB RJ45

Systems management (cổng  quản lý hệ thống):

A shared port for management and data.

System Fan Features (Hệ thống quạt tản nhiệt):

3 Fan Standart

Power Supply Type (Bộ nguồn

1x 250W AC  Power Supply

Expansion Slots (Khe cắm mở rộng):

4 PCIe 3.0

Optical Drive (Ổ đĩa quang):

OPTIONAL

Weight (Trọng lượng):

 maximum: 12.5 kg (27.6 lb)

Product Dimensions (Kích thước W x H x D):

Width: 175 mm (6.9 in.), height: 375 mm (14.8 in.), depth: 431 mm (17.0 in.)

Form Factor (Hình dáng bên ngoài):

Tower 4U

Warranty Standard Satement (Bảo hành tiêu chuẩn):

3  năm

Thông số kỹ thuật nâng cấp

Processor Type:

Intel

Processor Family:

2x Intel® Xeon E12xx V6, E12xx v5, core i3 6xxx-7xxx, celeron G39xx

Processor Core Available:

2  to 8  core, depending on model

Processor Cache Installed: ):

2-8  MB L3, depending on processor

Maximum Memory :

64GB  with (4 x16 GB) UDIMMs

Memory Slots:

4  Slot

Memory Type:

UDIMM

Drive Supported:

Up to 40 TB with 4x 10 TB 3.5-inch NL SATA HDDs

Up to 8 TB with 4x 2 TB 3.5-inch SATA HDDs

Up to 4.8 TB with 5x 960 GB 2.5-inch SATA SSDs

Storage Controller :

Non-RAID with the integrated SATA controller.

RAID 0, 1, 10, and 5 with ThinkServer RAID 121i.

RAID 0, 1, 10 with ThinkServer RAID 520i. Optional RAID 5, 50 upgrade

Network Controller:

1Gb 2-port Network Controller, depending on model

Remote Management :

A shared port for management and data.

System Fan Features (Hệ thống quạt tản nhiệt):

4 Fan Standart

Expasions Slots:

Up to 4  slots

Operating Systems and Virtualization Software

Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi. See the Operating systems section for specifics.

Warranty Standard Statement :

Server Warranty includes three years
